NEXUS
PANEL
10.1"
IE10260MCA-101ABJ
Quick Links
⇩
7.0" (800x480)
Starter Kit with CTP, IPS
Starter Kit with CTP
Product with CTP, IPS
Product with CTP
10.1" (1024x600)
Starter Kit with CTP, IPS
Product with CTP, IPS
10.1" 1024x600
Capacitive-Touch
IPS LCM
Features
Working with ADE for delivering illuminating HMI
Support customized combination of Ethernet, Wi-Fi, RS-485, RS-232, CAN bus, and NB-IoT
Support 10.1” 1024x600 IPS LCM with CTP from our partner
Feature ARM Cortex M7-based MCU @480Mhz with 32MB DRAM
Built-in 2Gb (256MB) Flash memory for storage
Support ARGB (16,777,216 colors) with 256 levels of transparency
Support LCM backlight control
Support GPIO, PWM, Input-Capture and ADC functions
Support UART communication interfaces
Support 12V~24V flexible DC input
Support I2C/SPI interfaces
4x 3.5mm holes for mounting tabs with M4 screws
Downloads
Datasheet
